DUMP BOX BASE FRAME
Part Breakdown Image

Fig #

1
DUMP BOX FRAME BASE

DUMP BOX FRAME BASE

Part Number: F2240A-A

DUMP BOX FRAME BASE (4 TUBE FRAME)


2
3/8in SAE WASHER

3/8in SAE WASHER

Part Number: U8590A-N

3/8in SAE WASHER

$  0.05

3
SCREW

SCREW

Part Number: U8515A-N

3/8-16 X 2 1/4in HEX HEAD CAP SCREW

$  0.63

4
NUT

NUT

Part Number: U8506A-N

3/8-16 SERRATED FLANGE HEX NUT

$  0.13

5
DUMP BOX PUMP COVER

DUMP BOX PUMP COVER

Part Number: F2242A-OO

DUMP BOX PUMP COVER


6
DUMP BOX PUMP COVER SUPP.

DUMP BOX PUMP COVER SUPP.

Part Number: F2243A-OO

DUMP BOX PUMP COVER SUPPORT


7
DUMP BOX PROP ROD

DUMP BOX PROP ROD

Part Number: F2244A-OO-BLK

DUMP BOX PROP ROD


8
SCREW

SCREW

Part Number: U8621A-N

3/8-16 X 2.75in HEX HEAD CAP SCREW

$  0.42

9
DUMP BOX PROP ROD RETAINER

DUMP BOX PROP ROD RETAINER

Part Number: F2223A-N

DUMP BOX PROP ROD RETAINER

$  3.56

10
SELF DRILLING PHIL PAN

SELF DRILLING PHIL PAN

Part Number: U8641A-N

8-18 X 1/2in SELF DRILLING PHIL PAN

$  0.05

11
VIBRATION-DAMPENING

VIBRATION-DAMPENING

Part Number: F2250A-N

LEVELING MOUNT VIBRATION-DAMPENING


12
NUT

NUT

Part Number: U8506A-N

3/8-16 SERRATED FLANGE HEX NUT

$  0.13

13
SCREW

SCREW

Part Number: U8555A-N

3/8-16 X 1in HEX HEAD CAP SCREW

$  0.34

14
DUMP BOX CAPACITY LABEL

DUMP BOX CAPACITY LABEL

Part Number: F2202A-N

DUMP BOX CAPACITY LABEL

$  3.71
